Feel like you're right in the scene with 3D surround sound
The JBL Bar 9.1 soundbar brings audio experience of a movie theater into your home with two detachable surround speakers and the added punch of Dolby Atmos® and DTS:X™ 3D sound. With 820 watts of total system power, you can enjoy every Oscar-worthy performance through powerful, crystal-clear audio. Turn up the 10’’ subwoofer for pulse-pounding bass or turn it down and relax with Chromecast and AirPlay music streaming. Immerse yourself in the latest blockbuster or re-live your favorite movie or sport scenes. The most incredible home cinema sound experience is here.
Power supply100 - 240VAC, ~ 50/60Hz
Battery charge time3 hours
Total speaker power output (Max. @THD 1%)820 W
Main Soundbar output power (Max. @THD 1%)400
Surround speakers output power (Max. @THD 1%)2 x 60W
Subwoofer output power (Max. @THD 1%)300
Soundbar transducer4×racetrack drivers + 2 × up-firing full-range drivers+3 × 0.75” (20mm) tweeter
Surround transducer (per piece)Up-firing full-range driver + 0.75” (20mm) tweeter
Subwoofer transducer10"
Operating temperature0°C - 45°C
Standby for Soundbar (when all wireless connections are deactivated)< 0.5 W
Networked standby (Soundbar)< 6.0 W
Networked standby (Subwoofer)< 2.0 W
Time to standby<10 minutes
HDMI In1
HDMI eARC1
HDMI HDCP version2.3
Connections1 Optical, Bluetooth, Chromecast, AirPlay2, USB
Soundbar dimensions (WxHxD)884 x 62 x 120 (mm), 34.8” x 2.4” x 4.7”
Detachable surround speaker, per piece173 x 60 x 120 (mm) / 6.8” x 2.4” x 4.7”
Subwoofer dimensions (WxHxD)305 x 440 x 305(mm) / 12.0" x 17.3" x 12.0"
Soundbar weight3.64 kg/ 8.0 lb
Detachable surround speaker0.72 kg x 2/ 1.6 lb x2
Subwoofer weight11.10 kg / 24.5 lb
USB port Type A
USB rating5 V/ 500 mA
Supported file formatMP3
MP3 codecMPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3
MP3 sampling rate16 KHz - 48 KHz
MP3 bitrate80 kbps - 320 kbps USB Port USB playback is available in US version. For other versions, USB is for Service only
Bluetooth version4.2Bluetooth profileA2DP V1.2/ AVRCP V1.5
Bluetooth frequency range2402MHz-2480MHz
Bluetooth Max. transmitting power13dbm (EIRP)
Modulation Type GFSK, π/4 DQPSK, 8DPSK
Wi-Fi networkIEEE 802.11 a/b/g/n/ac (2.4GHz/5GHz)
2.4G Wi-Fi frequency range2412 – 2472 MHz (2.4GHz ISM Band, USA 11 Channels, Europe and others 13 Channels)
2.4G Wi-Fi Max. transmitting power20 dBm (EIRP)
Modulation TypeDBPSK, DQPSK, CCK, QPSK, BPSK, 16QAM, 64QAM
5G Wi-Fi frequency range5.15 - 5.35 GHz, 5.470-5.725 GHz, 5.725 - 5.825 GHz
5G Wi-Fi Max. transmitting power22 dBm (EIRP)
Modulation TypeQPSK, BPSK, 16QAM, 64QAM, 256QAM
5G Wireless frequency range5180.0 - 5240.0MHz (Except Europe), 5725.0 - 5825.0MHz
5G Max. transmitting power13 dBm (EIRP)
Modulation TypeQPSK
- 1x Main Soundbar
- 2x Detachable wireless surround speakers
- 1x Wireless subwoofer
- Remote control with 2 x batteries
- Power cords (up to 8pcs depending on region SKUs)
- HDMI cable x1
- 2 x L-shape Wall-mount bracket (Main Bar) + 2 x U-shape Wall-mount bracket (for Surround Speakers) kit with screws
- Quick start guide
- Warranty card
- Safety sheet
